Introduction

Tunnel Communication Technology is essential for the safety and efficiency of tunnel operations. Effective communication between train crews, stations, and other operational points is crucial, especially in complex environments where thick walls and structures can block radio signals. Investing in advanced tunnel communication solutions ensures strong, continuous communication channels, critical for passenger safety and operational efficiency.

Types of Tunnel Communication Systems



Radio Communication System

Used for communication during maintenance, between train guards and drivers, and in emergencies. It includes:

  • VHF Simplex System: For human-to-human communication using walkie-talkies or base radios.
  • LocoTrol System: Coordinates braking and traction power distribution for machine-to-machine communication.
  • GSM-R/LTE System: Enables wireless communication in railway systems.
  • KAVACH (TCAS): An automatic train protection system to prevent collisions and signal passing at danger.

Emergency Telephones

Installed at key points in tunnels for quick access during emergencies, linked to the Emergency Control Communication System.

Public Addressing System (PAS)

Informs and instructs staff and passengers via loudspeakers under normal and emergency conditions.

Hotline Telephone

Provides emergency telephone services connected to Tunnel Maintenance Boxes and the Divisional Railway Exchange Centre.

Control and Monitoring System

Involves video surveillance cameras for continuous monitoring of tunnels, connected to the Tunnel Control Center.

Solution Components

  • Master Unit
  • Optical Remote Unit
  • Off-Air Channelized Repeater
  • OFC Cable
  • Leaky Cables
  • Antennas

Salient Features

  • Enhanced Safety: Facilitates efficient emergency communication, optimizing operational efficiency.
  • Operational Efficiency: Supports smooth operations with clear exchanges during critical situations.
  • Reliability: Ensures safe, efficient train movement, contributing to network reliability.
  • High-Speed Data Transmission: Utilizes fiber optic cables for fast data transfer with minimal interference.
  • Wireless Connectivity: Provides mobile device connectivity through Wi-Fi, Bluetooth, and cellular networks.
  • Hybrid Communication Approach: Combines wired and wireless technologies to tackle tunnel-specific challenges.
  • Interference Management: Reduces interference from physical obstacles, ensuring reliable communication.
